Label
Frequency band：866-928MHz Band
Size：43 x 43 mm,21.5 x 21.5 mm,30 x 30 mm
| Frequency band | 866-928MHz Band | ||
| Size | 43 x 43 mm | 21.5 x 21.5 mm | 30 x 30 mm |
|
Read range (Depends on the reader) |
Up to 10M | Up to 6M | Up to 7M |
| Testing reader | 1PRU258A0R2 | ||
| Transmission principle | passive | ||
| Antenna substrate | PET | ||
| Antenna material | copper | ||
| Tube size | 3inch | ||
| Operating temperature | -40°C ~ 75°C | ||
| Storage temperature | -20°C ~ 35°C | ||
| UID | 96 bits | ||
| EPC | 128 bits | ||
| ISO standard | EPC-C1G2,ISO-18000-6C | ||
| IC | M4D | ||
. UHF far-end tag
. Can be used in lane system, logistics, warehouse management, with wide practicality
. Easy to carry and paste
. Easy to track and manage
. Can be used in lane system, logistics, warehouse management, with wide practicality
. Easy to carry and paste
. Easy to track and manage
