Remote Control Transmitter
Specifications
| Frequency range |
320MHz (Can Customized 315MHz ; 434MHz) |
|
|---|---|---|
| Sensitivity | -106 dbm | |
| Noise equivalent BW NEB | 4KHz Max | |
| Channel width | ± 500 KHz | |
| Input voltage | AC 110 V | |
| Output current |
2A1B, 3A, 4A (Can Customized) |
|
| Function |
2 Momently / 1 Latch (Can Customized) |
|
| Weight | 172 g | |
| Size | 124 x 93 x 30mm(L x W x H) | |
- The New power supply circuit design, AC power input range:(AC 110V), the conversion efficiency is good and stable.
- The RF using wireless frequency, frequency stability and high sensitivity, Remote control distance.
- The Receive the main device up and down switching function.
- The Receive host with 2A1B, 3A, 4A function options can be full Enough user needs.
Features
Can be used with the following Hopping Code Remote Controller.
Remote Controller
RH227TU
Remote Controller
RH227TN
Remote Controller
RH227TA
Remote Controller
RH227TM
Remote Controller
RH227TKProduct Inquiry
| Image | Product Name |
|---|---|
|
Remote Control Receiver RH227 |
