RFID HF Module

Model : PMHNR32DBUV1
  • ．RS-485 interface.
  • ．Frequency Reader Module 13.56 MHz (frequency band).



  • ．External antenna connectivity.
  • ．Data transmission can customizable.
  • ．Supports：These interfaces allow the reader module to communicate with external devices such as computers(Windows 10/11), microcontrollers, or network servers.
  • ．Support IC：Mifare standard series、Mifare desfire series、I-Code series、NFC series.
  • ．Other support： external antenna, buzzer / station number - connect 255 stations / terminal block spacing 3.5mm.

Product Name RFID HF Module
Product No. PMHNR32DBUV1
Frequency band 13.56 MHz
Read range

5cm ±1 cm (External Antenna)

Interface

RS-485 (customizable)

Baud-Rate  115200, N, 8, 1  (customizable)
Input Voltage Range
 DC 12V ~ 24V
Dynamic mode 93 mA
Operating temperature -30℃ ~ 70℃
Storage temperature -30℃ ~ 70℃
Dimensions 60(L) x 32(W) x 15.5(H) mm
Audio / Visual Indication Buzzer、LED


HF reader supports


ISO-14443A/B/C
ISO-15693


Interface

Product No. PMHNR32DBUV1
Interface RS-485



Supported

Standard Manufacturer Tag Brand UID Read Write
ISO 15693 I-Code series Y Y Y
TiTag series Y Y Y
Suitable ISO 15693 series Y Y Y
ISO 14443A NFC series Y Y Y
Mifare standard series Y Y Y
Mifare desfire series
 Y Y Y
Mifare Ultralight series
 Y Y Y
Mifare Plus series
 Y Y Y
Suitable ISO 14443A series Y Y Y
ISO 14443B ATMEL series Y Y Y

． Industrial Control

． Production Automation

． Station Number Management

． Locker Management
