RFID LF Password & Proximity Card Reader
Frequency：125 KHz
Max range：14 ~ 20 cm
Model :
PRL5078
| Frequency band | 125 KHz | |
|---|---|---|
| Max range | 14 ~ 20 cm | |
| Reading time | 0.1 Sec | |
| Operating time | 0.6 Sec | |
| P.I.N.code | 4 Digital | |
| Output interface | Wiegand 26 bits | |
| Output relay | DC 5 A / 12 V | |
| Power supply input | DC 11 ~ 14 V | |
| Stand by current | 67 mA | |
| Operating current | 127 mA | |
| Card max capacity | 2000 | |
| 6000 | ||
| 10000 | ||
| Memory max capacity | 3000 | |
| 5000 | ||
| 7000 | ||
| 9000 | ||
| Baud rate | No | |
| Operating temperature | -30°C ～ +55°C | |
| Storage temperature | 0°C ～ +30°C | |
| Weight | 240 g | |
| Size | 154 x 88 x 33 mm(L x W x H) | |
- ．Password or Proximity Card is available.
- ．Maximum reading ranges 14-20cm.
- ．The capacity is 2000/ 6000/ 10000/ three installation.
- ．Random card numbers is available.
- ．Large LCD screen and 16 keypads Displaying 16 characters x 2 lines.
- ．LCD screen can display the Model, Date and Time when standby.
- ．Reader can record the data of come in and go out.
- ．The Original installation is 1000 records.
- ．Set up 3000/ 5000/ 7000/ 9000/ records that depend on the customers.
- ．Inquiring the data from Reader directly.
- ．Built-in the watch output. Compatible with the monitor system.
- ．Built-in tamper switch detects if case is under force.
- ．Increasing and deleting card numbers by keyboard directly.
- ．Set up the functions by keyboard directly. LCD display.
- ．Reader's memories are never deleted even if power failure.
- ．Sensor and Alarm will be started when the door is unlocked or under force.
- ．Compatible with the Reader (Wiegand 26 bit).
- ．Separating HW-5055 and Reader (Wiegand 26 bit) too indoors and outdoors.
